SPECIAL TOOLS
| TOOL | TOOL NUMBER AND NAME | REPLACED BY MILLER TOOL NUMBER | APPLICATION |
|---|---|---|---|
| MD998333 Oil pump remover |
MD998333 | Removal of oil pump | |
| MD998924 Spring compressor retainer |
8622 | Use with spring compressor | |
| MD998903 Spring compressor |
C-3775-A | Removal and installation of one-way clutch inner race snap ring < F4A42 > | |
| MD998338 Spring compressor |
5059-A | Removal and installation of one-way clutch inner race snap ring < F4A51 > | |
| MB991625 Socket (41) |
N/A | Removal and installation of transfer drive gear jam nut < F4A42 > | |
| MB990607 Torque wrench socket |
N/A | Removal and installation of output shaft nut | |
| MD998412 Guide |
MD998412 | Installation of oil pump and transfer drive gear | |
| MB991631 Clearance dummy plate |
MB991631 | Measurement of reaction plate low-reverse brake and second brake end plays < F4A42 > | |
| MB991632 Clearance dummy plate |
MB991632 | Measurement of reaction plate low-reverse brake and second brake end plays < F4A51 > | |
| MD998913 Dial gauge extension |
MD998913 | Measurement of low-reverse brake end play | |
| MB990938 Handle |
8590 |
|
|
| MB990930 Installer adapter |
8594 | Installation of output shaft taper roller bearing outer race | |
| MD998350 Bearing installer |
C-3717 | Installation of output shaft collar and taper roller bearing | |
| MB990931 Installer adapter |
MD998717 | Installation of cap | |
| MB990935 Installer adapter |
D-146 | Installation of differential taper roller bearing outer race < F4A42 > | |
| MB990936 Installer adapter |
D-146 | Installation of output shaft taper roller bearing outer race < F4A42 > and differential taper roller bearing outer race < F4A51 > | |
| MD998334 Oil seal installer |
MD998334 | Installation of oil pump oil seal | |
| MD998907 Spring compressor |
MD998907 | Removal and installation of underdrive clutch snap ring | |
| MB991628 Spring compressor |
MB991628 | Measurement of underdrive clutch and overdrive clutch end plays < F4A42 > | |
| MB991629 Spring compressor |
MB991629 | Measurement of underdrive clutch and overdrive clutch end plays < F4A51 > | |
| MD999590 Spring compressor |
MD998907 | Removal and installation of overdrive clutch snap ring | |
| MB991790 Spring compressor |
MB991790 | Measurement of reverse clutch end play < F4A42 > | |
| MB991789 Spring compressor |
8621 | Measurement of reverse clutch end play < F4A51 > | |
| MD998917 Bearing remover |
8595 | Removal of output shaft taper roller bearing and transfer driven gear< F4A42 > | |
| MD998801 Bearing remover |
P-334 | Removal of each bearing output shaft taper roller bearing (differential ball bearing) | |
| MD998812 Installer cap |
N/A | Use with installer and installer adapter | |
| MD998814 Installer - 200 |
N/A | Use with installer cap and installer adapter | |
| MD998823 Installer adapter (48) |
MD998805 | Installation of output shaft taper roller bearing < F4A42 > and transfer driven gear < F4A42 > | |
| MD998827 Installer adapter (56) |
C-3095A | Installation of output shaft taper roller bearing < F4A51 > | |
| MB990937 Installer adapter |
8592 | Installation of output shaft taper roller bearing < F4A51 > | |
| MD998813 Installer - 100 |
N/A | Use with installer cap and installer adapter | |
| MD998824 Installer adapter (50) |
C-3095A | Installation of transfer driven gear < F4A51 >, differential taper roller bearing < F4A51 > | |
| MD998820 Installer adapter (42) |
C-4965 | Installation of differential taper roller bearing | |
| MD998800 Oil seal installer |
MD9988325 | Installation of driveshaft oil seal |
