Without using scan tool MB991502

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Turn the ignition switch to the "ON" position while holding the auto-cruise control switch in the "SET" (down) position. Then, within one second, more the auto-cruise control switch up to the "RES" position.
  2. Check to make sure the "CRUISE" light on the instrument panel is flashing.
  3. Put the auto-cruise control switch in the "SET" (down) position. Depress the brake pedal and hold for five seconds or more. Release the brake pedal, auto-cruise control switch, then turn the ignition switch to the "LOCK" (OFF) position. The DTC(s) are now erased.
    Fig 1: Identifying Ignition Switch Direction
    G04539300Courtesy of DAIMLERCHRYSLER CORPORATION
