< 2.4L Engine >

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Removing/Installing Water Hose And Water Pipe (2.4L Engine)
G04537377Courtesy of DAIMLERCHRYSLER CORPORATION
