<< D >> Engine Mount Bracket Removal

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
  1. Support the engine with a garage jack.
  2. < Engine lifter MZ203827 is used >

    Remove special tools MB991453 and MZ203827 which were attached when the transaxle assembly was removed.

    Fig 1: Removing Special Tools MB991453 And MZ203827
    G04538349Courtesy of DAIMLERCHRYSLER CORPORATION
  3. < Engine hanger MB991895 is used >

    Remove special tools MB991895 which were attached when the transaxle assembly was removed.

    Fig 2: Removing Special Tools MB991895
    G04538350Courtesy of DAIMLERCHRYSLER CORPORATION
  4. < Engine hanger MB991928 is used >

    Remove special tools MB991454 and MB991895 which was attached when the transaxle assembly was removed.

    Fig 3: Removing Special Tools MB991454 And MB991895
    G04538351Courtesy of DAIMLERCHRYSLER CORPORATION
  5. Hold the engine assembly with a chain block or similar tool.
  6. Place a garage jack against the engine oil pan with a piece of wood in between, jack up the engine so that the weight of the engine is no longer being applied to the engine mount bracket, and then remove the engine mount bracket.
    Fig 4: Removing Engine Mount Bracket
    G04538352Courtesy of DAIMLERCHRYSLER CORPORATION
