<< B >> Cylinder Head Assembly Removal

WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION: Be careful not to damage or deform the plug guides when removing the cylinder head bolts. Plug guides cannot be replaced separately.

Using special tool MB991654, loosen the bolts in two or three steps in the order of the numbers shown in the illustration, then remove the cylinder head assembly.

Fig 1: Removing Cylinder Head Assembly Using Special Tool
G04538166Courtesy of DAIMLERCHRYSLER CORPORATION
