Installation Procedure

WARNING: This page is about a different variant/trim than selected.
  1. GM4537735Courtesy of GENERAL MOTORS COMPANY

    Connect the transmission vent hose assembly (3) to the transmission hose adapter (2).

  2. Connect the transmission vent hose assembly retainers (1) to the transmission vent hose clip bracket.
  3. Install the plenum front panel. Plenum Front Panel Replacement (LT1 LT4)
