Removal Procedure

WARNING: This page is about a different variant/trim than selected.
  1. GM5551340Courtesy of GENERAL MOTORS COMPANY

    Using the J-44737  Shift Rail Bearing Remover (1) and J-2619-01  Slide Hammer (2) remove the transfer case four wheel drive actuator lever shaft bearing (4).
