Single Use Fasteners and Components
WARNING: This page is about a different variant/trim than selected.
Camshaft Position Actuator Magnet Gasket
| Callout | Component Name |
|---|---|
| Preliminary Procedure Drive Belt Replacement - Accessory (LT1) |
|
| 1 | Camshaft Position Actuator Fasteners (Qty: 3)
CAUTION:
Refer to Fastener Caution . Tighten 10 N.m (89 lb in) |
| 2 | Camshaft Position Actuator Magnet Procedure Unplug the camshaft position actuator magnet electrical connector. |
| 3 | Camshaft Position Actuator Magnet Gasket
NOTE:
Replace with NEW gasket |
