Torque Converter and Differential Housing Cleaning and Inspection
WARNING: This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Torque Converter And Differential Housing Components For Cleaning And Inspection
| Callout | Component Name |
|---|---|
|
CAUTION:
After cleaning the transmission components, allow to air dry. Do not use cloth or paper towels in order to dry any transmission components. Lint from the towels can cause component failure.
CAUTION:
Do not reuse cleaning solvents. Previously used solvents may deposit sediment which may damage the component.
CAUTION:
Preliminary ProceduresThoroughly clean the torque converter housing, including case threads with clean solvent.Do not use abrasive pads or bristle devices to clean the sealing surfaces. Abrasive pads produce a fine grit that can effect transmission function. Abrasive pads can also remove enough metal to create oil leaks. |
|
| 1 | Threaded Hole |
| 2 | Threaded Hole |
| 3 | Gasket Sealing Surface |
| 4 | Transmission Fluid Filler Hole Plug |
| 5 | Automatic Transmission Case Hole Plug [2x]
CAUTION:
Refer to Fastener Caution . Tighten 10.5 N.m (93 lb in) |
| 6 | Vent Pipe |
