Reverse Carrier Installation

WARNING: This page is about a different variant/trim than selected.
GM4675201Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
1 Reverse Carrier Thrust Washer [2x]
2 Reverse Carrier
