Crankshaft Balancer Installation
WARNING: This page is about a different variant/trim than selected.
Special Tools
- EN-45059 Angle Meter
- EN-48034 Crankshaft Balancer Installer
- EN-51760 Flywheel Holding Tool
For equivalent regional tools, refer to Special Tools .
To prevent crankshaft rotation, install EN-51760 flywheel holding tool (2) and starter motor bolts (1) at the starter motor location and engaging the flywheel.
Using EN-48034 installer, install the crankshaft balancer (2).
- Install a NEW crankshaft balancer bolt and washer. Tighten the bolt to 150 N.m (111 lb ft) plus 140 degrees using the EN 45059 meter.
- Remove EN-51760 flywheel holding tool.
CAUTION:
Refer to Fastener Caution .
CAUTION:
This vehicle is equipped with torque-to-yield or single use fasteners. Install a NEW torque-to-yield or single use fastener when installing this component. Failure to replace the torque-to-yield or single use fastener could cause damage to the vehicle or component.
