Fuel Injection and Components
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 1 | Valve Lifter Follower |
| 2 | Fuel Pump Seal |
| 3 | Fuel Pump |
| 4 | Fuel Pump Bolt [2x] |
| 5 | Fuel Pump Insulator |
| 6 | Fuel Feed Intermediate Pipe Bolt |
| 7 | Fuel Feed Intermediate Pipe - High Pressure |
| 8 | Fuel Injection Fuel Rail Bolt [4x] |
| 9 | Fuel Injection Fuel Rail Wiring Harness |
| 10 | Fuel Injection Fuel Rail Insulator |
| 11 | Fuel Injection Fuel Rail |
| 12 | Fuel Injection Fuel Rail Fuel Pressure Sensor |
| 13 | Fuel Injector Nozzle Housing Seal [8x] |
| 14 | Fuel Injector [4x] |
| 15 | Fuel Injector Seal Spacer [4x] |
| 16 | Fuel Injector Seal [4x] |
| 17 | Fuel Injector Retainer [4x] |
| 18 | Fuel Injector Retainer Clamp [4x] |
