Ignition and Start Switch Replacement

GM5131885Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
Preliminary Procedure
Radio Control Assembly Replacement
1 Ignition and Start Switch
Procedure
Release the retaining tabs.
