Front of Vehicle Components (Chevrolet)
Front of Vehicle Components (Chevrolet)
| Component Name | Callout |
|---|---|
| B174W Frontview Camera - Windshield (UFL) B174W Frontview Camera - Windshield | 1 |
| E13LA Headlamp Assembly - Left | 2 |
| E29LF Fog Lamp - Left Front (T3U) E29LF Fog Lamp - Left Front | 3 |
| B9 Ambient Air Temperature Sensor B9 Ambient Air Temperature Sensor | 4 |
| E29RF Fog Lamp - Right Front (T3U) E29RF Fog Lamp - Right Front | 5 |
| E13RA Headlamp Assembly - Right | 6 |
