Installation Procedure
WARNING: This page is about a different car, the 2019 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
Install the oil pump flow control wiring harness (2) to the oil pan.
- Install the oil pump flow control wiring harness bolt (1) and tighten to 10 N.m (89 lb in)
Connect the wiring harness (1) to the oil pump flow control harness.
Connect the oil pump flow control valve harness connection (1).
- Lower Oil Pan Replacement - Install
CAUTION:
Refer to Fastener Caution .
