Sunroof Control Block Diagram (C3U)

WARNING: This page is about a different car, the 2019 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
M69	M69 Sunroof Motor
K9	K9 Body Control Module
A98	A98 Front Overhead Console Assembly
M81	M81 Sunroof Sunshade Motor
