Rear Floor Panel Carpet Replacement
Courtesy of GENERAL MOTORS COMPANY
Callout
Component Name
Preliminary Procedures
Front Seat Removal and Installation
Rear Seat Cushion Removal and Installation
Front Floor Console Replacement
Center Pillar Lower Trim Panel Replacement
1
Rear Floor Panel Carpet
Procedure
Release the retainer and remove the front power seat connectors from the floor pan structure.
Reposition front floor panel carpet as needed.
