Upper Left Side of the Engine Components (LV1)
WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
Upper Left Side of the Engine Components (LV1)
| Items |
|---|
| 1: B20 Brake Fluid Level Switch B20 Brake Fluid Level Switch |
| 2: Q12 Evaporative Emission Purge Solenoid Valve (LV1, L96, or LC8) Q12 Evaporative Emission Purge Solenoid Valve (L96/LC8) , or Q12 Evaporative Emission Purge Solenoid Valve (LV1) |
| 3: B74 Manifold Absolute Pressure Sensor B74 Manifold Absolute Pressure Sensor (L96/LC8) , or B74 Manifold Absolute Pressure Sensor (LV1) |
| 4: B75C Multifunction Intake Air Sensor B75C Multifunction Intake Air Sensor |
| 5: T8E Ignition Coil 5 T8E Ignition Coil 5 (L96/LC8) , or T8E Ignition Coil 5 (LV1) |
| 6: T8C Ignition Coil 3 T8C Ignition Coil 3 (L96/LC8) , or T8C Ignition Coil 3 (LV1) |
| 7: T8A Ignition Coil 1 T8A Ignition Coil 1 (L96/LC8) , or T8A Ignition Coil 1 (LV1) |
