Rear HVAC with Rear Air Conditioning (C69), without Rear HVAC Controls - Air Delivery Controls
WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 341 | Run Ignition 3 Voltage |
| 341_BN | 341 BN |
| CAV_G | G |
| CAV_C3 | C3 |
| CONN_X2 | X2 |
| 341_BN | 341 BN |
| 2599 | Rear Mode Motor Signal |
| 2599_GY | 2599 GY |
| CAV_J | J |
| 2599_GY | 2599 GY |
| 2599_GY | 2599 GY |
| 2775 | Rear Air Temperature Motor Control |
| 2775_OG | 2775 OG |
| CAV_H | H |
| 2775_OG | 2775 OG |
| 2775_OG | 2775 OG |
| 1850 | Ground |
| 1850_BK | 1850 BK |
| CAV_F | F |
| 1850_BK | 1850 BK |
| CAV_B | B |
| 1926 | Auxiliary Blower Motor Low Speed Control |
| 1926_D-BU | 1926 D-BU |
| CAV_C | C |
| 1925 | Auxiliary Blower Motor Medium Speed Control |
| 1925_OG | 1925 OG |
| CAV_E | E |
| 1924 | Auxiliary Blower Motor High Speed Control |
| 1924_WH | 1924 WH |
| CAV_D | D |
| 1926_D-BU | 1926 D-BU |
| 1925_OG | 1925 OG |
| 1924_WH | 1924 WH |
| X407 | X407 |
| CAV_F | F |
| CAV_A | A |
| X205 | X205 |
| CAV_6 | 6 |
| CAV_4 | 4 |
| CAV_12 | 12 |
| X205 | X205 |
| CAV_14 | 14 |
| CAV_2 | 2 |
| CAV_5 | 5 |
| G348 | G348 |
| F13PA | F13PA 10A |
| K_REF | K |
| L_REF | L |
| H_REF | H |
| J_REF | J |
| M_REF | M |
| J311 | J311 |
| J310 | J310 |
| J308 | J308 |
| X407 | X407 |
| X205 | X205 |
| X205 | X205 |
| Interior_Lights_Dimming_Wiring Schematics_REF | Interior Lights Dimming Wiring Schematics |
| S34F | S34F HVAC Controls Switch Assembly - Auxiliary Front (C36 or C69) |
| KR74 | KR74 Ignition Run Relay |
| X52A | X52A Fuse Block - Passenger Compartment |
| M37B | M37B Mode Door Actuator - Auxiliary (C69) |
| M6B | M6B Air Temperature Door Actuator - Auxiliary (C69) |
