Installation Procedure
WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
Front Shock Absorber Lower Insulator (3)@Front Shock Absorber (2) - Install
- Front Shock Absorber (2) - Install
- Front Shock Absorber Bolt (1) - Install and tighten [2x] 25 N.m (18 lb ft)
Front Shock Absorber Upper Insulator (2)@Front Shock Absorber (3) - Install
- Front Shock Absorber Nut (1)@Front Shock Absorber (3) - Install and tighten22 N.m (16 lb ft)
- Remove the jack stand from beneath the front lower control arm.
Front Wheelhouse Splash Shield (3) - Install - Wheelhouse Splash Shield Replacement (Left Side) , or Wheelhouse Splash Shield Replacement (Right Side)
- Install the front tire and wheel assembly. Tire and Wheel Removal and Installation (Without Dual Rear Wheels) , or Tire and Wheel Removal and Installation (With Dual Rear Wheels)
- Remove the support and lower the vehicle.
- Dispose of the front shock absorber. Shock Absorber Disposal
CAUTION:
Refer to Fastener Caution .
