Removal Procedure
WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
- Recover the refrigerant. Refrigerant Recovery and Recharging
- Front Grille - Remove - Front Grille Replacement (Chevrolet) , or Front Grille Replacement (GMC)
- Air Conditioning Refrigerant Pressure Sensor - Remove - Air Conditioning (A/C) Refrigerant Pressure Sensor Replacement
- Disconnect and reposition the hood primary and secondary latch electrical connector and wire harness out of the way.
Headlamp- Left Side (4) - Remove - Front Headlamp Replacement
Air Conditioning Compressor and Condenser Hose Nut (3) @ Air Conditioning Condenser - Remove
- Air Conditioning Compressor and Condenser Hose (2) @ Air Conditioning Condenser - Remove
- Remove and DISCARD the sealing washer. (1) Air Conditioning System Seal Replacement
Front Wheelhouse Splash Shield-Right Side (3) - Remove - Wheelhouse Splash Shield Replacement (Right Side)
Air Conditioning Compressor and Condenser Hose Bolt (2) @ Air Conditioning Compressor - Remove
- Air Conditioning Compressor and Condenser Hose (1) @ Air Conditioning Compressor - Remove
- Remove and DISCARD the sealing washer. (3) Air Conditioning System Seal Replacement
- Disconnect the electrical connector.
- Remove the air conditioning compressor and condenser hose (1) from the vehicle.
