Removal Procedure
WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
Engine Coolant Fan Lower Shroud (1) - Remove - Engine Coolant Fan Lower Shroud Replacement (LV1)
Air Conditioning Compressor Belt (3) - Remove - Air Conditioning Compressor Belt Replacement
{ If equipped } Vacuum Pump Belt (3) - Remove - Vacuum Pump Belt Replacement
Install the EN-52287 Balancer Holding Kit (1) and the EN-956 - 1 Extension Bar (2) to the crankshaft balancer (3).
Crankshaft Balancer Bolt (1) - Remove and DISCARD
- Remove the EN-52287 Balancer Holding Kit and the EN-956 - 1 Extension Bar.
Install the EN-41816 - A Crankshaft Balancer Remover (1) and the EN-44226 - 5 Crankshaft Protector, and use tool adjustment to release the crankshaft balancer (2).
- Once the crankshaft balancer (2) has released, remove the EN-41816 - A Crankshaft Balancer Remover (1) and the EN-44226 - 5 Crankshaft Protector.
Crankshaft Balancer (1) - Remove
- Crankshaft Balancer (1) - Clean and inspect - Crankshaft Balancer Cleaning and Inspection
