Repair Instructions
>>
Turn Signal Bulb Replacement - Left Side (SBV)
Turn Signal Bulb Replacement - Left Side (SBV)
Callout
Component Name
1
Turn Signal Lamp Bulb Socket
Procedure
Rotate the bulb socket a quarter turn counterclockwise and remove.
2
Turn Signal Bulb - Left Side
Procedure
Pull the bulb from the bulb socket.
