Instrument Panel Compartment Lamp Replacement

GM4711446Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
Preliminary Procedure
Front Floor Rear Console Side Trim Panel Replacement - Left Side
1 Instrument Panel Compartment Lamp

Procedure

  1. Open the armrest cover.
  2. Disconnect the electrical connector.
  3. Release the tab at the bottom of the lamp while guiding the switch out of the opening to remove the lamp assembly.
  4. Using a flat-bladed tool, lift the bottom of the lamp and tilt inward from the console.
