Hood Latch

WARNING: This page is about a different car, the 2017 Chevrolet Spark. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Hood Latch
GM4322465Courtesy of GENERAL MOTORS COMPANY
