Rear Seat Back Cushion Cover And Pad Replacement (40%)

Preliminary Procedures

1. Rear Seat Back Cushion Removal and Installation (40%) Rear Seat Back Cushion Removal and Installation (60%) .
2. Rear Seat Head Restraint Guide Replacement .

Procedure

1. Disengage the J-channel retainers from the seat back cushion frame.
2. Open the right and left seat back cushion cover zippers.
3. Remove the seat back cushion cover and pad from the seat cushion frame as an assembly.

Procedure

1. Separate the seat cushion cover from the seat cushion pad by removing all hog rings, disengaging the hook and loop fasteners and pulling the cover away from the pad.
2. Transfer components as necessary.
