Exhaust Pressure Differential Sensor Pipe Installation

WARNING: This page is about a different variant/trim than selected.
Fig 1: Exhaust Pressure Differential Sensor Pipe And Components
GM2900092Courtesy of GENERAL MOTORS COMPANY
  1. Install the exhaust pressure differential sensor pipe (5).
    2. CAUTION:

    Refer to Fastener Caution .

  2. Install the exhaust pressure differential sensor pipe bracket bolt (4) and tighten to 9 N.m (80 lb in).
  3. Install 2 NEW clamps (6) to the hoses.
  4. Connect the hoses to the catalytic converter connection pipes (1) and fasten the clamps (6).
  5. Install 2 NEW clamps (3) to the hoses.
  6. Connect the hoses to the exhaust pressure differential sensor (2) and fasten the clamps (3).
