Transmission Fluid Pump, Front Differential Carrier Baffle, and Front Differential Ring Gear Removal (6T40/45)
WARNING: This page is about a different car, the 2019 Buick Cascada, 2018 Buick Cascada, and 2017 Buick Cascada. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 1 | Front Differential Carrier Baffle Bolts M6 x 25 (Qty: 2) |
| 2 | Front Differential Carrier Baffle |
| 3 | Front Differential Ring Gear Retainer
NOTE:
Note the direction of the taper to ensure proper installation. |
| 4 | Front Differential Ring Gear |
| 5 | Fluid Pump Bolts M8 x 33 (Qty: 8) |
| 6 | Fluid Pump Assembly |
| 7 | Torque Converter and Differential Housing Seal |
