Drive Motor Power Inverter Module Cooling Outlet Hose Replacement

WARNING: This page is about a different variant/trim than selected.
Fig 1: Drive Motor Power Inverter Module Cooling Outlet Hose
GM4322227Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
Preliminary Procedure
Drain the drive motor generator power inverter module cooling system. Refer to Drive Motor Generator Power Inverter Module Cooling System Draining and Filling
1 Generator Control Module Coolant Pump Hose Clamp [2x]
Procedure
Hose Clamp Replacement Guidelines - Spring Type
2 Drive Motor Power Inverter Module Cooling Outlet Hose

Procedure

  1. Fill the cooling system to the proper level.
  2. Inspect for coolant leaks.
