Torque Converter Housing with Fluid Pump Assembly Installation

WARNING: This page is about a different variant/trim than selected.

Fig 1: Torque Converter Housing with Fluid Pump Assembly

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
1	Front Differential Carrier Bearing
2	Automatic Transmission Fluid Pump Seal NOTE: Install a NEW seal. Do NOT reuse the old seal.
3	Torque Converter Housing Gasket NOTE: Install a NEW gasket. Do NOT reuse the old gasket.
4	Torque Converter Housing NOTE: Rotate the differential slightly in each direction using the rotating tool to align the Differential Pinion Gears with the Differential Ring Gear in the Torque Converter Housing. DT-47793 Differential Rotating Tool Special Tools DT-47793 Differential Rotating Tool Equivalent regional tools: Special Tools
5	Torque Converter and Differential Housing Bolt [14x] CAUTION: Refer to Fastener Caution . Tighten in sequence 38 N.m (28 lb ft)
