Transmission Control Lever Boot Replacement

WARNING: This page is about a different car, the 2015 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Transmission Control Lever Knob & Retainers
GM2869793Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
1 Transmission Control Lever Knob Retainer (Qty: 6)
Procedure
Squeeze the shifter boot at the arrows, then using a flat-bladed plastic trim tool, release the rear retainer clip securing the control lever boot.
2 Electrical connector
3 Transmission Control Lever Knob
NOTE:
  • The control lever boot and knob are replaced as an assembly.
  • To remove the knob, pull upward and twist.
