Rear Seat Bolster Airbag Replacement

Fig 1: Rear Seat Bolster Airbag

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure Disable the SIR system, if equipped. Refer to SIR Disabling and Enabling . Remove the rear seat back cushion bolster. Refer to Rear Seat Back Bolster Replacement .
1	Rear Seat Bolster Airbag Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 3.5 N.m (31 lb in)
2	Rear Seat Bolster Airbag Nut (Qty: 2) Tighten 3.5 N.m (31 lb in)
3	Rear Seat Bolster Airbag Support Bracket
4	Rear Seat Bolster Airbag Module Procedure Remove the connector position assurance (CPA) from the module electrical connector. Disconnect the electrical connector.
