Rear Seat Cup Holder Replacement

Fig 1: Rear Seat Cup Holder
GM3230064Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
1 Rear Seat Cup Holder
Procedure
Remove the rear seat cup holder by gently pulling the whole cup assembly forward releasing the two lower tabs.
