| 1 |
PCV Valve Bolt |
| 2 |
PCV Valve |
| 3 |
PCV Tube Assembly |
| 4 |
Valve Rocker Arm Oil Control Valve Assembly Bolt |
| 5 |
Valve Rocker Arm Oil Control Valve Assembly Bolt |
| 6 |
Valve Rocker Arm Oil Control Valve Assembly |
| 7 |
Valve Rocker Arm Oil Control Solenoid Valve Housing Gasket |
| 8 |
PCV Valve Bolt |
| 9 |
PCV Valve |
| 10 |
Camshaft Cover Bolt |
| 11 |
Engine Oil Manifold Gasket |
| 12 |
Oil Flow Check Valve Housing Assembly |
| 13 |
Oil Flow Check Valve Housing Assembly Bolt |
| 14 |
Ignition Coil Bolt |
| 15 |
Ignition Coil |
| 16 |
Spark Plug |
| 17 |
Camshaft Cover Bolt |
| 18 |
Camshaft Cover Bolt |
| 19 |
Oil Level Indicator |
| 20 |
Camshaft Housing Cover Heat Shield Bolt |
| 21 |
Camshaft Housing Cover Heat Shield |
| 22 |
Spark Plug Shield Seal |
| 23 |
Camshaft Position Actuator Control Solenoid Valve - Exhaust |
| 24 |
Camshaft Position Actuator Control Solenoid Valve Bolt - Exhaust |
| 25 |
Camshaft Cover Gasket |
| 26 |
Camshaft Cover |
| 27 |
Engine Oil Pressure Sensor |
| 28 |
Camshaft Position Actuator Control Solenoid Valve - Intake |
| 29 |
Camshaft Position Actuator Control Solenoid Valve Bolt - Intake |
