Front Seat Belt Anchor Plate Tensioner Replacement

Fig 1: Front Seat Belt Anchor Plate Tensioner Components

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
WARNING: Refer to SIR Seatbelt Pretensioner Handling Warning . Preliminary Procedures Remove the front seat lower finish cover.
1	Front Seat Belt Tensioner Cap
2	Front Seat Belt Tensioner Fastener CAUTION: Refer to Fastener Caution . Tighten  5 N.m (44 lb in)
3	Front Seat Belt Tensioner Cover
4	Front Seat Belt Tensioner Seat Belt Latch Procedure  Remove the seat belt with latch from front seat belt tensioner.
5	Front Seat Belt Tensioner Fastener Tighten  55 N.m (41 lb ft)
6	Front Seat Belt Tensioner Procedure  Disconnect the electrical connector.
