1st/2nd Gear Synchronizer
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 1 | 2nd Gear Gearwheel |
| 2 | 2nd Gear Inner Synchronizer Ring |
| 3 | 2nd Gear Middle Synchronizer Ring |
| 4 | 2nd Gear Outer Synchronizer Ring |
| 5 | 1st/2nd Gear Selector Sleeve |
| 6 | Spring Catches |
| 7 | 1st/2nd Gear Sleeve Carrier |
| 8 | Spacer |
| 9 | 1st Gear Outer Synchronizer Ring |
| 10 | 1st Gear Middle Synchronizer Ring |
| 11 | 1st Gear Inner Synchronizer Ring |
| 12 | 1st Gear Gearwheel |
| 13 | 1st Gear Axial Needle Bearing |
