Windshield Washer Pump Hose Replacement (Trax)
WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of GENERAL MOTORS COMPANY
| Callout |
Component Name |
|
Preliminary Procedures
- Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle
.
- Remove the front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement (Trax)
.
|
| 1 |
Windshield Washer Pump Hose Procedure
- Place a collecting container under the windshield washer solvent container.
- Disconnect the windshield washer pump hose from the windshield washer pump.
- Lower the vehicle.
- Disconnect the windshield washer pump hose from the connection piece at the air inlet grille panel.
- Remove the windshield washer pump hose from the two clips on the windshield washer solvent container.
NOTE:
Observe the routing of the windshield washer pump hose for installation purposes.
|
