Installation Procedure

WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Engine Oil Pressure Indicator Switch
    GM2191866Courtesy of GENERAL MOTORS COMPANY
  1. Install the oil pressure indicator switch (1) and a NEW oil pressure indicator switch seal ring (2).
    2. CAUTION:

    Refer to Fastener Caution .

  2. Tighten the oil pressure indicator switch to 20 N.m (15 lb ft).
