Inspection Procedure

WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front wheel drive shaft inner joint and boot. Refer to Front Wheel Drive Shaft Inner Joint and Boot Replacement .
    2. Fig 1: Identifying Wheel Drive Shaft Inner Joint Inspection Areas
    GM2056507Courtesy of GENERAL MOTORS COMPANY
  2. Remove the wheel drive shaft tripod bushing (1) from the tripod housing (3).
  3. Remove the wheel drive shaft tripod housing (3) from the wheel drive shaft.
  4. Remove the wheel drive shaft tripod joint boot bushing (1).
  5. Using a suitable cleaner, remove the excess grease from the tripod assembly.
  6. Inspect the following items for damage or excessive wear:
    • The wheel drive shaft tripod boot
    • The wheel drive shaft tripod assembly
    • The wheel drive shaft tripod joint housing
    • The wheel drive shaft tripod joint bushing
    • The wheel drive shaft
  7. If any of the internal parts are found to be excessively worn or damaged, replace the wheel drive shaft inner joint and boot. Refer to Front Wheel Drive Shaft Inner Joint and Boot Replacement .
