Park Brake Hardware Inspection
WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.
- Visually inspect the park brake lever (1) and the lever pivot pin (2) for the following conditions:
- The lever being bent or broken at any point - particularly at the cable attachment
- A seized or binding condition at lever pivot pin
- A broken lever pivot pin
- If any of the conditions listed were found, the park brake lever and brake shoe assembly requires replacement.
WARNING:
Refer to Brake Dust Warning .
NOTE:
The brake shoe and park brake lever are not serviced separately. If either component requires replacement, they must be replaced as an assembly.
