Front Side Door Window Outer Sealing Strip Replacement
WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of GENERAL MOTORS COMPANY
| Callout |
Component Name |
| 1 |
Front Side Door Window Outer Sealing Strip Procedure
- Do Not remove the outside rearview mirror.
- Use the appropriate tool, lift the rear corner of the sealing strip and pull upward and away from the door flange.
- Press firmly to insert the front side door window sealing strip back on the door flange.
- Inspect the door window for proper operation.
|
