Mode Control Cam Actuator Replacement (C67)

WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Mode Control Cam Actuator (C67)

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedures Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection . Remove the steering column assembly. Refer to Steering Column Replacement (Mexico, N40)Steering Column Replacement (Canada, NJ1)Steering Column Replacement (United States, NJ1) .
1	Mode Control Cam Actuator Fastener (Qty: 2)
2	Mode Control Cam Actuator Procedures Disconnect the mode control cam actuator connector. Perform the actuator re-calibration procedure. Refer to Actuator Recalibration (C67) .

Callout

Component Name

Preliminary Procedures

Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
Remove the steering column assembly. Refer to Steering Column Replacement (Mexico, N40)Steering Column Replacement (Canada, NJ1)Steering Column Replacement (United States, NJ1) .

Mode Control Cam Actuator Fastener (Qty: 2)

Mode Control Cam Actuator

Procedures

Disconnect the mode control cam actuator connector.
Perform the actuator re-calibration procedure. Refer to Actuator Recalibration (C67) .
