Driver Information Display Replacement (UAG)

WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Driver Information Display Replacement (UAG)

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
1	Instrument Panel Upper Trim Panel Bracket Refer to Instrument Panel Upper Trim Panel Bracket Replacement (UAG) .
2	Driver Information Display Procedure Disconnect the electrical connections. Refer to Control Module References for programming and set up information.

Callout

Component Name

Instrument Panel Upper Trim Panel Bracket
Refer to Instrument Panel Upper Trim Panel Bracket Replacement (UAG) .

Driver Information Display

Procedure

Disconnect the electrical connections.
Refer to Control Module References for programming and set up information.
