Memory Seat System Components
WARNING: This page is about a different car, the 2015 Chevrolet Trax and 2015 Buick Encore. However, it is still accessible from the selected car via links, so may be relevant.
The memory seat system consists of the following components:
- Driver seat adjuster switch
- Driver seat memory switch
- Seat memory control module
- Seat horizontal motor/sensor
- Seat front vertical motor/sensor
- Seat rear vertical motor/sensor
| Callout | Component Name |
|---|---|
| S64D | S64D Seat Adjuster Switch - Driver |
| S47D | S47D Seat Memory Switch - Driver |
| K40 | K40 Seat Memory Control Module |
| M50D | M50D Seat Front Vertical Motor - Driver |
| M55D | M55D Seat Rear Vertical Motor - Driver |
| M51D | M51D Seat Horizontal Motor - Driver |
