Behind the Engine Components

Powertrain Component Views

Behind the Engine Components (L20, L96, L9H, LC9 or LMG)





1 - Heated Oxygen Sensor (HO2S) - Bank 1 Sensor 1

2 - Heated Oxygen Sensor (HO2S) - Bank 2 Sensor 1

3 - Heated Oxygen Sensor (HO2S) - Bank 2 Sensor 2

4 - Heated Oxygen Sensor (HO2S) - Bank 1 Sensor 2
