Hood Front Seal Replacement
Hood Front Seal Replacement
Fig 1: Hood Front Seal
Courtesy of GENERAL MOTORS COMPANY
Hood Front Seal Replacement
Callout
Component Name
1
Hood Front Seal Retainer (Qty: 5)
2
Hood Front Seal
Courtesy of GENERAL MOTORS COMPANY
