29. Lower Intake Manifold Cover Removal - Right Side

Lower Intake Manifold Cover Removal - Right Side

Special Tools

J 37228 - Seal Cutter

For equivalent regional tools, refer to Special Tools Special Tools.





1. Remove the right intake manifold bolts. Do not forget to remove the bolt inside the intake manifold tube.

2. Separate the intake manifold from the cylinder head using - cutter.

3. Remove the right intake manifold.
