103. Lower Intake Manifold Cover Installation - Left Side

Lower Intake Manifold Cover Installation - Left Side





1. Apply a 2-3 mm wide by 0.5-1.5 mm high bead of GM P/N 12378521 (Canadian P/N 88901148) sealant on the intake manifold mating surface.





2. Install the intake manifold (1, 2, 3).





Caution:
Refer to Fastener Caution Fastener Caution.

3. Install the intake manifold bolts and nuts and tighten to 25 Nm (18 lb ft).
