Lock Pillar Upper Garnish Molding Replacement (Sedan)

Fig 1: View Of Lock Pillar Upper Garnish Molding (Sedan)

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Screw Upper Quarter Trim Cover
2	Upper Quarter Trim Screw CAUTION: Refer to Fastener Caution . Tighten:  2 N.m (18 lb in)
3	Upper Quarter Trim Panel Assembly
4	Upper Quarter Trim Clip
