Front Seat Head Restraint Guide Replacement

Fig 1: Front Seat Head Restraint Guide
GM1551173Courtesy of GENERAL MOTORS CORP.
Callout Component Name
Fastener Tightening Specifications:  Refer to Fastener Tightening Specifications .

Preliminary Procedures

  1. Remove the head restraint. Refer to Driver or Passenger Seat Head Restraint Replacement .
  2. Partially remove the seat back cover. Refer to Driver or Passenger Seat Back Cushion Cover and Pad Replacement .
1 Guide, Head Restraint
